QuietForm, DuneWall  //  Tiles + Shapes

QuietForm™ Tiles are a thermal molded acoustics product, designed for a three-dimensional wall finish with transformative soundscaping functionality. Drawing inspiration from the captivating essence of timeless architecture, our QuietForm patterns pay homage to the grandeur of history’s most iconic structures.

Request A Quote
Design Symbols

Colorways

Colorways

QuietForm, Dune

Shiraz

SH63

Quartz

QU67

Celery

CE65

Flint

FL64

Granite

GR62

Almond

AL55

Turmeric

TU60

Walnut

WA56

Umber

UM54

Flamingo

FL61

Sea Salt

SE57

Currant

CU59

Sencha

SE58

White

WH12

Pearl

PE21

Ivory

IV11

Platinum

PL04

Metal

ME03

Grey

GR02

Slate

SL27

Charcoal

CH01

Piano Black

PI24

Pistachio

PI25

Peach

PE19

Lilac

LI13

Periwinkle

PE23

Marine

MA15

Iris

IR10

Thistle

TH28

Oregano

OR18

Kale

KA12

Denim

DE09

Midnight

MI16

Peppercorn

PE22

Popcorn

PO26

Carrot

CA08

Berry

BE06

Azure

AZ05

Peacock

PE20

Wasabi

WA29

Shiraz

SH63

Quartz

QU67

Celery

CE65

Flint

FL64

Granite

GR62

Almond

AL55

Turmeric

TU60

Walnut

WA56

Umber

UM54

Flamingo

FL61

Sea Salt

SE57

Currant

CU59

Sencha

SE58

White

WH12

Pearl

PE21

Ivory

IV11

Platinum

PL04

Metal

ME03

Grey

GR02

Slate

SL27

Charcoal

CH01

Piano Black

PI24

Pistachio

PI25

Peach

PE19

Lilac

LI13

Periwinkle

PE23

Marine

MA15

Iris

IR10

Thistle

TH28

Oregano

OR18

Kale

KA12

Denim

DE09

Midnight

MI16

Peppercorn

PE22

Popcorn

PO26

Carrot

CA08

Berry

BE06

Azure

AZ05

Peacock

PE20

Wasabi

WA29

Details

.45 – .75

Minimum Acoustic NRC Rating

QuietForm™ Tiles possess soundscaping properties that effortlessly reshape the acoustics of any space by absorbing excess noise and reducing reverberation.

The Noise Reduction Coefficient (NRC) rating is dependent on sound frequencies and mounting methods:

  • 0.45 (no air gap)
  • 0.60 (20mm air gap)
  • 0.75 (50mm air gap)

Sustainability

We help designers, architects, and owners meet their clean building goals by testing all of our products against internationally recognized environmental and human safety standards to protect our employees, our customers, and future generations. Read more about our sustainability work here.

Specs

Surface

Wall


Composition

100% Polyester


Material

Filasorb™


Recycled Content

60% minimum


NRC Rating

.45 – .75 minimum


Thickness

1/2″ (12mm)


Dimensions

24″ x 24″


Fire Tests

AS ISO 9705: 2003 Group 1, ASTM E84-17a Class A, ISO 9705: 1993 Group 1

CAN/ULC S102-2018


Lead Time

3-6 weeks


Origin

Manufactured and Assembled in the USA

Custom

Acoufelt design engineers stand ready to serve on your design team, marrying their deep understanding of the art and science of sound management to your vision with custom cutting, printing, shaping, and technical advice to soundscape your designs.

Talk to us.

How to specify

Specify Step 1

1. Choose your surfaces
Soundscape your space by placing enough sound absorption where it has the greatest impact. Hint: adjoining surfaces with sound absorbing materials reduce reverberation faster.

Specify Step 2

2. Select a color, pattern, or cut
Choose from our broad palette and pattern gallery, or use our custom capabilities to design your own.

Specify Step 3

3. Measure your installation space
Take the dimensions and get in touch so we can help you soundscape your space efficiently.
